High brightness outdoor waterproof P5 led fixed display wall
Technical Parameter
|
Value
|
FOT4
|
FOT5
|
FOT6
|
FO10T
|
|
Pixel pitch (mm)
|
4
|
5
|
6
|
10
|
|
Pixel configuration
|
SMD
|
SMD
|
SMD
|
SMD
|
|
Brightness (nits)
|
4500-6500
|
4500-6500
|
4500-6500
|
4500-6500
|
|
Grey scale ( level )
|
14 bit
|
14 bit
|
14 bit
|
14 bit
|
|
Pixel Matrix Per Panel
|
240*240
|
192*192
|
160*160
|
320*160
|
|
Pixel Matrix Per Sq.m
|
62500
|
40000
|
27777
|
10000
|
|
Viewing Angle (H/V)
|
140 /140
|
140 /140
|
140 /140
|
140/140
|
|
Refresh rate (Hz)
|
≥1920
|
≥1920
|
≥1920
|
≥1920
|
|
IP grade ( F / R)
|
IP65/ IP54
|
IP65/ IP54
|
IP65/ IP54
|
IP65/ IP54
|
|
Input voltage ( V )
|
AC220V±10%
|
AC220V±10%
|
AC220V±10%
|
IP65/ IP54
|
|
Power Consumption (Max / Avg)
|
1000/ 350 w/sq.m
|
1000 /350 w/sq.m
|
1000 / 350 w/sq.m
|
1000 / 350 w/sq.m
|
|
Size (L x W x D mm)
|
960*960*120
|
960*960*120
|
960*960*120
|
960*960*120
|
|
Panel weight (Kgs)
|
38(Iron)
|
38 (Iron)
|
38 (Iron)
|
38 (Iron)
|
